Analog peripheral devices

SIMATIC S7-1500, ANALOG OUTPUT MODULE AQ 2 X U/I ST; 16 BITS OF RESOLUTION, ACCURACY 0.3 %; 2 CHANNELS IN GROUPS OF 2; DIAGNOSIS, SUBSTITUTE VALUE INCL. FRONT CONNECTOR PUSH-IN, FEEDING ELEMENT, SHIELDING ELE- MENT, SHIELDING CLAMP

SIMATIC S7-1500, ANALOG OUTPUT MODULE AQ 4 X U/I ST; 16 BITS OF RESOLUTION, ACCURACY 0.3 %; 4 CHANNELS IN GROUPS OF 4; DIAGNOSIS, SUBSTITUTE VALUE

SIMATIC S7-1500 Analog input/output module AI 4x U/I/R/RTD/TC ST; 4 channels in groups of 4; Hardware interrupts; Diagnostics AQ 2x U/I ST; 2 channels in groups of 2; Substitute value; Diagnostics Common mode voltage approx. 10 V 16 bit; Accuracy 0.3%; Delivery including push-in front connector, infeed element, shield bracket and shield terminal

SIMATIC S7-1500, Analog input module AI 8xU/I/RTD/TC ST, 16 bit resolution, Accuracy 0.3%, 8 channels in groups of 8, 4 channels for RTD measurement, Common mode voltage 10 V; diagnostics; Hardware interrupts incl. infeed element, Shield bracket and shiel

SIMATIC S7-1500, Analog input module AI 8xU/I HF, up to 24 bit resolution, Accuracy 0.1%, 8 channels in groups of 1, Common mode voltage: 30V AC/60V DC, diagnostics; Hardware interrupts Measured values scalable, Measuring range adjustment, Calibrate in RUN incl. infeed element, Shield bracket and shield terminal

SIMATIC S7-1500, ANALOG INPUT MODULE AI 8 X U/R/RTD/TC HF, 16 BITS OF RESOLUTION, UP TO 21 BITS OF RESOLUTION WITH RTD AND TC, ACCURACY 0.1%, 8 CHANNELS IN GROUPS OF 1; COMMON MODE VOLTAGE: 30V AC/60V DC, DIAGNOSIS, PROCESSALARMS; SCALABLE MEASURED TEMPERATURE RANGE, THERMOCOUPLE TYPE C, CALIBRATION AT RUN, INCL. INFEED ELEMENT, SHIELD CLAMP AND SHIELD TERMINAL

SIMATIC S7-1500, analog input module AI 16xI BA, 16-bit resolution accuracy 0.5%, 16 channels in groups of 16, common mode voltage 4 V DC, diagnostics, hardware interrupts; delivery including infeed element, shield bracket and shield terminal: front connector (screw terminals or push-in) to be ordered separately

SIMATIC S7-1500, ANALOG INPUT MODULE AI 4 X U/I/RTD/TC, 16 BITS OF RESOLUTION, ACCURACY 0.3 %; 4 CHANNELS IN GROUPS OF 4; COMMON MODE VOLTAGE APPR. 10 V; DIAGNOSIS, PROCESSALARMS INCL. FRONT CONNECTOR PUSH-IN, FEEDING ELEMENT, SHIELDING ELE- MENT, SHIELDING CLAMP

SIMATIC S7-1500 Analog input module, AI 8xU/I/R/RTD BA, 16 bit resolution, Accuracy 0.5%, 8 channels in groups of 8; Common mode voltage 4 V DC, Diagnostics; Hardware interrupts; Delivery including infeed element, shield bracket and shield terminal: Front connector (screw terminals or push-in) to be ordered separately

SIMATIC S7-1500, Analog output module AQ 4xU/I HF, 16 bit resolution, Accuracy 0.1%, 4 channels in groups of 1, Common mode voltage: 30V AC/60V DC, diagnostics; Substitute value Isochronous mode incl. infeed element, Shield bracket and shield terminal

SIMATIC S7-1500, ANALOG INPUT MODULE AI 8 X U/I HS, 16 BITS OF RESOLUTION, ACCURACY 0.3 %; 8 CHANNELS IN GROUPS OF 8; COMMON MODE VOLTAGE APPR. 10V; DIAGNOSIS, PROCESSALARMS; 8 CHANNELS IN 0,125 MS

SIMATIC S7-1500, Analog output module AQ8xU/I HS, 16 bit resolution, Accuracy 0.3%, 8 channels in groups of 8, diagnostics; Substitute value 8 channels in 0.125 ms oversampling incl. infeed element, Shield bracket and shield terminal
